High Efficiency Netting Gabion Mesh Machine Basket Production Line Max Width 4300mm
Gabion Mesh Machine Benifits
1. Gabion mesh machine is also called heavy duty hexagonal wire mesh machine, gabion machine , stone cage making machine.
2. This gabion machine weave hexagonal mesh vertically.
The KS series automatic gabion machine includes four main standard parts: Main netting machine, winding machine, wire tension device and spiral coiling machine, it can produce gabions of various widths and mesh sizes.
Automatic Gabion Mesh Machine:
Konson brand gabion machine refers to the machine for making of hexagonal wire netting, it is also known as heavy type hexagonal wire netting machine. Our machine is specially used to produce the large size and heavy duty hexagonal (galvanized, galfan & PVC wire) wire meshes for the fence and the stone gabions usage. It has several models for different sizes of meshes and the maximum netting width is up to 4.3 meters. We can also supply the complete production line for your whole netting workshop.
Specification:
| MODEL | MESH SIZE | MAX.WIRE DIA. | MAX WIDTH | PRODUCING RATE |
| KS6080-2.4 | 60X80 mm | 3.0mm | 2400mm | >3.3 m/min |
| KS6080-3.2 | 3.5mm | 3200mm |
| KS6080-4.0 | 3.5mm | 4300mm |
| KS80100-2.4 | 80X100 mm | 3.5mm | 2400mm | >3.5 m/min |
| KS80100-3.2 | 3.5mm | 3200mm |
| KS80100-4.0 | 4.0mm | 4300mm |
| KS100120-2.4 | 100X120 mm | 3.5mm | 2400mm | >3.5 m/min |
| KS100120-3.2 | 3.5mm | 3200mm |
| KS100120-4.0 | 4.0mm | 4300mm |
| KS120150-2.4 | 120X150 mm | 4.0mm | 2400mm | >3.8 m/min |
| KS120150-3.2 | 4.0mm | 3200mm |
| KS120150-4.0 | 4.0mm | 4300mm |
